Oxford Ascend Stand-Aid Lift

Oxford
Specify all product options to determine final product price.

The Oxford Ascend has the capabilities can transfer a patient from a low-seated position to fully standing with ease. The Ascend prompts an active lifting motion which helps to encourage user participation, which helps to promote patient independence and well-being.

With its excellent range of movement, the Oxford® Ascend can transfer a patient from a low-seated position to fully standing with ease. Its active lifting motion is designed to encourage user participation, promoting ongoing patient independence and well-being.The Ascend gives the option of both a standing and a transport sling to help the carer perform a variety of tasks including; toileting, standing, point to point transfers, and walking and rehabilitation activity. The Ascend is compact and easy to operate which makes it easy to operate in confined spaces.
Technology featured:

  • Smart™ Monitor diagnostic control system
  • Ergonomic design considerations
  • Powered leg positioning
  • Removable foot tray
  • Height adjustable knee pad
Please choose all product options to determine final product price.
Dimensions

Safe working load

200kgs

Maximum overall length

110cm

Minimum overall length

100cm

Maximum overall height

171cm

Minimum overall height

107cm

Maximum height to attachment point

166.5cm

Minimum height to attachment point

99cm

Turning radius

132cm

Legs open - external width

99.5 cm

Legs open - internal width

88.5cm

Legs closed - external width

63cm

Legs closed - internal width

51cm

Overall height of legs

12cm

Ground clearance

3.5cm

Front twin castors

10cm

Rear braked castors

10cm
